USB Type-C to VGA Dongle
Part Number: RUB31-XXXX
(Note: The part number is only for reference. If you have requirement,
please contact Amphenol for further confirming PN and drawing)
Product Description: USB Type-C To VGA Dongle
Series: Type-C
Plating(Type-C): Au 30u'' min
Plating(VGA): Au 15u" min over Ni 50u" min
Color: Black
Environmental Compliance: RoHS
Flammability: UL94 V-0, raw cable VW-1

USB Type-C to VGA Dongle

Part Number: RUB31-XXXX
(Note: The part number is only for reference. If you have requirement,
please contact Amphenol for further confirming PN and drawing)
Product Description: USB Type-C To VGA Dongle
Series: Type-C
Plating(Type-C): Au 30u'' min
Plating(VGA): Au 15u" min over Ni 50u" min
Color: Black
Environmental Compliance: RoHS
Flammability: UL94 V-0, raw cable VW-1

Applications

1.    Notebook

2.    TV

3.    Monitor

4.    Projector

5.    Consumer electronic



Features and Benefits

1.    Transmission rate: 5.4Gbps

2.    Transfer Type-C signal to VGA signal

3.    Compliance with Type-C 1.1 Specification



Mechanical Performance

   Mating Force and Un-mating Force

   1. Type-C plug connector

       Condition: EIA 364-13. Insert and extract at a speed of 25mm/minute.

Mating Force: 5N-20N

Un-mating Force: 8N-20N



   2. VGA plug connector

       Condition: EIA 364-13. Insert and extract at a speed of 25mm/minute.

Mating Force: 44.1N maximum

       Un-mating Force: 9.8N-39.2N



Product Environmental Compliance

RoHS2.0: Compliant

China RoHS: Yes
REACH SVHC: Yes
Low-Halogen Status: Not reviewed



Packing

Per Amphenol‘s Site Operating Procedure #SOP-708 REV 2
