Applications
1. LED street light
2. LED power source
3. Outdoor display module
Features and Benefits
1. Screw locking to ensure reliable connection
2. IP rating IP67
3. Withstand outdoor harsh operating environment
Mechanical Performance
1. Ambient temperature range: -40℃-85℃
2. Mated cycle : 50 times min.
3. Terminal retention force: Min. 60G
Electrical Performance
1. Current Rating : 10A
2. Voltage Rating: 220V
3.Dielectric Withstanding Voltage: 500 VAC for 1 minute no breakdown
4. Insulation Resistance: 100 MOhm minimum.
5. Contact resistance: Max 1mOhm
Material Property
1. Male terminal: Brass
2. Female terminal: Phosphor copper
3. Insulator: Thermoplastic
4. Waterproof seal: Silicon rubber
Product Environmental Compliance
RoHS2.0: Compliant
ChinaRoHS:Yes
REACH SVHC:Yes
Low-Halogen Status:Not Reviewed
Packing
Per Amphenol‘s Site Operating Procedure #SOP-708 REV 2
|
