Applications
1. Servers
2. Data Storage
3. Desktops
4. Workstation
Features and Benefits
1. Data speed: 8GT/s
2. Meet OCuLink specification.
Mechanical Performance
1. Mating Force (w/out latch): 2~20N.
Connector W/Passive latch: 8~40N
2. Un-mating Force (w/out latch): 1~16N
Connector W/Passive latch: 8~25N
3. Rated durability cycles: 50 cycles MIN.
Electrical Performance
1. Voltage: 30VDC per contact
30mohm max. initial, 15mohm maximum after stress test.
2. Dielectric Withstanding Voltage: 250 VDC minimum for 100 ms
3. Insulation Resistance: 100 MΩ minimum between adjacent terminal
Signal Integrity
1. Mated Connector Impedance: 85 ohm±15%
2. Common Mode Impedance: meet PCIe Gen3 specification
3. Insertion loss: meet PCIe Gen3 specification,
4. Maximum Crosstalk: meet PCIe Gen3 specification
Product Environmental Compliance
RoHS2.0: Compliant
China RoHS: Yes
REACH SVHC: Yes
Low-Halogen Status: Not Reviewed
Packing
Per Amphenol‘s Site Operating Procedure #SOP-708 REV 2
|
