Applications

1.      Digital Signage

2.      LED signboards in streets and in stadiums

3.      Video and audio system

4.      Security systems

Features and Benefits

1.      Support max 50 meters video and audio signal transmission,length can be customized

2.      Bandwidth and speed rate DP1.4 spec, 8.1Gbps 4 channels, support 8k at 60Hz and 4k at 120Hz high resolution video

3.      Support hot plug without driver software

4.      Need not external power

5.      Power consumption: Source side 85mW at 3.3V, Display side 290mV at 3.3V

6.      DisplayPort plug own latch

7.      Optical fiber own lighter and smaller over 50% than traditional copper solution

8.      Excellent EMI performance

9.      Working / storage temperature: 0~+50°C / -20~+70°C

Product Environmental Compliance

RoHS2.0: Compliant

China RoHS: Yes
REACH SVHC: Yes
Low-Halogen Status: Not Reviewed

Packing

        Per Amphenol‘s Site Operating Procedure #SOP-708 REV 2
